PEROVSKITE TYPE COMPOSITE OXIDE

ホーム > HOME > Research and Development > Introduction on technology > PEROVSKITE TYPE COMPOSITE OXIDE

Overview

Technology cultivated in the development of barium titanate (BaTiO3) is applied mainly for production of perovskite-type oxide shown as ABO3.
In particular, strontium titanate (SrTiO3) can be used as high dielectric and low loss filler for investigations into the modification of dielectric property in high molecular materials and base materials of solid electrolytes and semiconductor ceramics in a similar manner to barium titanate.
  • PEROVSKITE TYPE COMPOSITE OXIDE
  • PEROVSKITE TYPE COMPOSITE OXIDE
  • PEROVSKITE TYPE COMPOSITE OXIDE

Marketed items and examples of powder properties

ItemCAS NO.Chemical formulaParticle size
(μm)
Specific surface area
(m2/g)
Strontium Titanate(ST) 12060-59-2 SrTiO3 0.8 2
Calcium Titanate(CT) 12049-50-2 CaTiO3 1 2.6
Barium Zirconate(BZ) 12009-21-1 BaZrO3 0.3 10
Barium Titanate149(BT149) 12009-31-3 BaTi4O9
※In addition to the above, some compound oxides shown as BaxCa(1-x), TixZr(1-x) O3, BaxSr(1-x), TiO3, etc. are available.
Please feel free to contact us.

Applications

Capasitor materials
Materials for microwave ceramics (GHz bandwidth), etc.
High dielectric constant and low dielectric loss filler
Solid oxide fuel cell (SOFC) materials
Semiconductor ceramic materials
Additives
■Alternative name: Perovskite-type oxide
■CAS registration no.: Refer to the production item above
■Chemical formula: Refer to the production item above

Please contact us for inquiries about Research and Development
