Overview

BESPA( Oxalate Method Barium Titanate )
CAS No.12047-27-7

BESPA BT is barium titanate (BaTiO3) synthesized by oxalate method.
Barium titanate has been used traditionally as capacitor material because of its high dielectric characteristic. In particular, it has made great contributions in the improvement of electronic circuit performance through use in dielectric layer of multi-layer ceramics capacitor (MLCC).

  • BT180nm
  • BT420nm
  • BT580nm

Because of the shift towards smaller, higher capacity, and thinner MLCC, there is demand for smaller particle sizes of barium titanate as the main ingredient. We are polishing the manufacturing technology of barium titanate by oxalate method to lead development into the field of nano particles.

  • BT50nm
  • BT100nm

Also, barium titanate particles can be dispersed in polymer materials (such as resins and rubbers) as high dielectric constant fillers to modify the materials into highly dielectric materials. In order to meet these demands, we have a wide variety of products ranging from fine particles (2μm ) to large particles (6–8 μm).

  • BT-UP2 2um
  • BTD-UP 8um

Characteristic of BESPA BT

The followings are the characteristics of the oxalate method.

  1. 1Barium titanate with stable composition (Ba/Ti ratio) can be obtained
  2. 2Able to synthesize high-purity product
  3. 3Particles with narrower particle size distribution can be obtained

Applications

  • Dielectric material for MLCC
  • Various capacitor materials
  • High dielectric filler
  • Inorganic EL insulation materials
  • Additives

Example of powder property

ItemParticle size (μm)Specific surface area (m2/g)Impurities (ppm)
BESPA BT 0.3 3.5

Fe2O3:less than 20
Na2O:less than 10
MgO:less than 10

0.6 1.9
2 0.8

■Synonym:Oxalate Method Barium Titanate

■CAS No.12047-27-7

■Chemical formula:BaTiO3
